HOME Battery Test Equipments CE-6000 Series CE-6000 Cell Testing System

Testing is the path to
extraordinary achievements.

Modular power units that
adapt to change.

±0.05% F.S.
Voltage Accuracy
±0.05% F.S.
±0.05% F.S.
Current Accuracy
±0.05% F.S.
100Hz
Recording Frequency
100Hz
20ms
Minimum Pulse Width
20ms
≤2ms
Current Response Time
≤2ms
≤5ms
Current Conversion Time
≤5ms

AC/DC and DC/DC dual-stage high-frequency isolation modular design, combined with low temperature drift and high-performance multi-channel 24-bit analog-to-digital converter chip, the steady-state accuracy is higher than that of traditional equipment.

All-around product tour.

Flexibly parallel, simply and efficiently.

The channel-independent parallel and split function enables testing of batteries in different power ranges, while the modular parallel function supports high-current battery module testing.

Flexibly parallel, simply and efficiently for CE-6000 Cell Testing System

Full-power energy feedback.
Multi-scenario energy savings.

75%
Feedback Efficiency (Max)
75%

The system can recover energy generated from battery discharge and redistribute it to other battery channels or feed it back to the internal power grid.

Powerful programmability.
Meet diverse testing needs.

Comprehensive equipment functionality, compatible with both charging and discharging, and adaptable to various BMS systems.

DBC configuration
 CC & CV charge/discharge test
20ms pulse width
Driving simulation
DBC configuration
CC & CV charge/discharge test
20ms pulse width
Driving simulation
Communication can be achieved by editing the DBC protocol files corresponding to different protocols of batteries.
CC charging or discharging until the voltage reaches the specified value, and then seamlessly switching to CV mode for battery compensation which is smooth without any spikes.
Testing the performance of the battery under fast changes in current/power.
Supports up to 1 million lines of changing data.

Perpetual dedication to safety protection.

● Grid Over/Under-Voltage Protection

● AC Short-Circuit and Phase Loss Protection

● Over-Voltage/Over-Current Output Protection

● Overheating Protection

● Open/Short Circuit Protection

● Emergency Stop Protection

● Self-Diagnosis Protection

● Redundant Voltage Channels Protection

● DC Polarity Reverse Protection

● Power-Off Resumption Protection

● Grid Voltage Phase and Frequency Adaptive

● Adjustable Protection Values for Voltage and Current

● Traceable Protection Log

Perpetual dedication to safety protection for CE-6000 Cell Testing System

Extensive peripheral devices.
Create a multi-dimensional testing environment.

Integrated peripheral devices such as Auxiliary Voltage, Auxiliary Temperature, and Environmental Test Chambers for comprehensive testing and evaluation, providing multi-dimensional and quantifiable support for battery mass production testing.

Extensive peripheral devices. Create a multi-dimensional testing environment. for CE-6000 Cell Testing System

We offer powerful auxiliary equipments
and accessories to provide comprehensive testing support for battery testing.

We offer powerful auxiliary equipments and accessories to provide comprehensive testing support for battery testing.
