CT-4008Q-5V100mA-124

For Coin Cells, Super Capacitors, Three-Electrode Systems Testing and etc.

Voltage & Current	Range / Current
Voltage & Current	Range 1	Range 2	Range 3	Range 4
5V100mA	0.2μA ~ 0.1mA	0.1mA ~ 1mA	1mA ~ 10mA	10mA ~ 100mA

*Other models can be customized according to voltage and current requirements.

Unit modularity,
powerful performance.

Current Accuracy
±0.01% F.S.

Recording Frequency
10Hz

Sampling Time
100ms

Current Response Time
(10% F.S. ~ 90% F.S.)
≤1ms

Minimum Pulse Width
500ms

Off-Line Test
1GB

Stable performance parameters to ensure accurate and reliable test data. At the same time, the product adopts modular design with each unit having 8 channels, which can be independently data acquisition and programmed with the maximum number of editable lines supporting 254 lines.

4-range switching,
precision defined.

Current ranges from 0.5μA ~ 0.1mA, 0.1mA ~ 1mA, 1mA ~ 10mA , 10mA ~100mA can be selected to realize the controllable accuracy of small current in small range.

Compact in size,
big on functionality.

With a height of 1U*, thin and compact body, it occupies minimal space while offering numerous testing capabilities. Multiple units can be assembled onto a gantry, allowing easy storage and fulfilling the requirements for testing multiple batteries.

Multiple testing modes.
One equipment, unlimited capabilities.

Cycle Life Test

Rate Charging / Discharging Test

Pulse Simulation Test

GITT Test

DCIR Test

dQ/dV Curve

Tailored for advanced battery testing: enabling dQ/dV differential capacity curve analysis capability.

dQ/dV differential capacity curve analysis graph

Powerful programmability.
Meet diverse testing needs.

The software is fully functional, covering a variety of work-step settings, recording, and data storage to meet a wide range of testing needs.

CC & CV charge/discharge test

DBC Configuration

500ms pulse width

Segmented recording

CC charging or discharging until the voltage reaches the specified value, and then seamlessly switching to CV mode for battery compensation which is smooth without any spikes.

Support import/edit/export of DBC files. Different battery pack protocols can be communicated by simply modifying the code of the DBC protocol file without upgrading the program.

Testing the performance of the battery under fast changes in current/power.

Allow to set up to 3 segment recording conditions per step, including voltage, current and time.

Perpetual dedication to safety protection.

● Discharge Data Protection

● Offline Testing Function

● Voltage Upper Limit Setting

● Voltage Lower Limit Setting

● Current Upper Limit Setting

● Current Lower Limit Setting

● Capacity Upper Limit Setting

● Delay Time Setting

NEWARE-CT-4008Q-5V100mA-124 Battery Tester different function introduction images

Extensive peripheral devices.
Create a multi-dimensional testing environment.

Integrated peripheral devices such as Auxiliary Voltage, Auxiliary Temperature, and Environmental Test Chambers for comprehensive testing and evaluation, providing multi-dimensional and quantifiable support for battery mass production testing.

The NEWARE-CT-4008Q-5V100mA-124 Battery Tester can connect to a wide range of peripherals

NEWARE-CT-4008Q-5V100mA-124 Battery Tester front view

Technical Specifications

Equipment name	CT-4008Q-5V100mA-124
Voltage
CV output range	10mV~5V
Min discharge voltage	-5V
Accuracy	± 0.01% of F.S.
Stability	± 0.02% of F.S.
Current
Output range/channel	Range1: 0. 2 μA-0.1mA Range2: 0.1mA-1mA Range3: 1mA-10mA Range4: 10mA-100mA
Accuracy	± 0.01% of F.S.
CV cut-off current	Range1：0.1μA Range2：1μA Range3：1μA Range4：0.1mA
Stability	± 0.02% of F.S.
Power
Output power/channel	0.5W
Stability	± 0.1% of F.S.
Time
Current response time	Max rising time:1.5ms
Working step time	≤(365*24)h/step Time format-00：00：00.000(h、m、s、ms)
